Azimuth Deep Diver

Courtesy of Azimuth

The “crème de la crème” of the Xtreme-1 range is the Deep Diver which comes in a seldom seen and attempted; square titanium case. What is ground breaking in this design is the fact that a square case is traditionally extremely difficult to waterproof. However, Azimuth managed to tackle this problem by ingeniously creating a separate capsule to house the ETA 2826 Big Date movement which is then inserted into the square case housing and held securely by 6 screws.

Courtesy of Azimuth

The Deep Diver is also equipped with a Helium Escape Valve (HEV) which allows the wearer to dive to a depth of 1500m and 2000m respectively without the dangers of the crystal popping off due to atmospheric pressures building up inside the watch case. In order to be able to withstand pressures at this depth, Azimuth created the crystal in this watch to be double domed to give it added strength.

Courtesy of Azimuth

Xtreme-1 Deep Diver
Mvt: Automatic ETA 2826-2 encapsulated in a movement capsule and further protected by an anti magnetic dust cover.
Beat: High beat 28,800 A/h
Function: Big Date. Automatic with 46 hour power reserve.
Case: 56.5mm x 46mm x 20mm (LxBxH). One piece high grade Titanium equipped with Helium Gas Escapement Valve.
Crystal: Double domed Sapphire, double coated.
Sapphire thickness: 4.00mm.
Winding Crown: Screw down waterproof Titanium crown.
Bezel: Single directional ratcheting bezel with Super Luminova depth markings.
Dial/Hand Set: Super Luminova filled markers and Hands.
Strap/Bracelet: Rubber strap with Deployant buckle.
Waterproof: 2,000m / 6562ft.

US Retail Price $4,500

Courtesy of Azimuth

www.azimuth-watch.com
